Autocad 2018 - Dibujar rectángulos y polígonos - Tutorial básico 09

Learning Drawing Tools

In this section, the speaker introduces drawing tools and focuses on creating rectangles and polygons using specific techniques.

Creating Rectangles Manually

• Creating rectangles manually involves a simple process of clicking to place points.

• The first click locates the initial point, while the second click positions the opposite corner.

• Rectangles can also be created by inputting numerical data for sides, allowing precise dimensions like 10 meters by 20 meters.

Utilizing Different Options for Shapes

• Exploring various options in the toolbar enhances shape customization.

• Features like chamfer (chaflán) and fillet (empalme) offer design variations.

• Pressing 'C' key changes settings, enabling adjustments such as chamfer distance or fillet length.

Editing Rectangles and Polygons

• Manipulating shapes post-creation provides flexibility in design modifications.

• Shapes can be edited by moving from central points or deforming them.

• Adding or removing vertices allows for intricate adjustments to shapes like rectangles and polygons.

Working with Polygons

• Understanding polygon creation involves specifying the number of sides for diverse shapes.

• Polygon tools enable shaping triangles to octagons with ease.
